KR0005 RC Tri-Tracked Tank Mobile Robot Kit with Camera

This is an extension kit base on RC Tri-Tracked (remotely-controlled triangle) tank mobile robot kit which used an aluminum extrusion fix on top plate to mount a camera moves on caterpillar tracks. A video stream about exploring the environment was taken by camera is transmitted to a computer or lap-top. The kit can be controlled remotely via a joystick.

The kit comes with following parts

• 2 rubber tracks
• 2 DC motors
• 1 Joystick
• 1 Camera
• 1 Aluminum extrusion
• 1 12V, 3500mA lithium battery
• 1 12V charger

Specifications

• Dimensions: 300mm x 260mm x 172mm
• Distance between bottom and ground: 43mm
• Chassis material: Aluminum alloy
• Color: Blue
• Speed: 0.4m/s
• Net weight: 6kg
• Load capacity: 8.5kg

DC motor specifications

• Type: Faulhaber 12V DC Coreless Motor
• Power: 17W
• No Load Speed: 8100RPM/minute
• Reduced Speed: 120RPM/minute
• Diameter: 30mm
• Length: 42mm
• Total Length: 85mm
• Diameter of Shaft: 6mm
• Length of Shaft: 35mm
• No Load Current: 75mA
• Load Current: 1400mA
• Gearbox Ratio: 64:1
